Full Color 2.4 Inch TFT LCD Screen Display 240x320 Dots 24pin 16 Bit Parallel LCD Display
Our Product Introduction
for more products please visit us on lcdtftscreen.com
Basic Information
Place of Origin:
China
Brand Name:
BBI
Certification:
ISO90001 RoHS
Model Number:
BBI-001
Minimum Order Quantity:
1000
Price:
0.7-7USD
Packaging Details:
CARTON
Delivery Time:
3-47WEEKS
Payment Terms:
T/T
Supply Ability:
100000/MONTH
Product Specification
Name:
2.4 Inch TFT LCD Screen Display
Compatibility:
Windows, Mac, Linux
Color Gamut:
SRGB 100%
Backlight Type:
LED
Response Time:
5 Ms
Touchscreen:
No
Size:
2.4 Inches
Highlight:
Full Color TFT LCD Screen
,2.4 Inch TFT LCD Screen Display
,16 Bit Parallel LCD Display
Our Product Introduction
for more products please visit us on lcdtftscreen.com
Product Description
Full Color 2.4 Inch TFT LCD Screen Display 240x320 Dots 24pin 16 Bit Parallel LCD Display
Product Description
| NO. | ITEM | SPECIFICATIONS |
| 1 | Product Name | 2.4-inch Full-Color TFT LCD Screen Display |
| 2 | LCD Type | TN Transmissive, QVGA |
| 3 | Viewing Angle | 12 O'clock |
| 4 | Resolution |
240x320 dots
|
| 5 | Working Voltage | 2.8~3.3V |
| 6 | Operating Temperature | -20~+70℃ |
| 7 | Storage Temperature | -30~+80℃ |
| 8 | FPC Connector | 24 pins, ZIF type |
| 9 | Pitch | 0.5 mm |
| 10 | Driver IC(COG) | ILI9341 |
| 11 | Interface | MCU 16-bit Parallel |
| 12 | Backlight Type | 4 LEDs, White |
| 13 | Power Consumption | VF=3.2V, IF=20*4mA |
| 14 | Brightness | 250 cd/m2 |
| 15 | Outline Dimension | 42.72(W)* 60.26(H)* 2.3(T) mm |
| 16 | Active Area | 36.72(W)* 48.96(H) mm |
| 17 | Touch Panel | Without |
Packaging & Shipping:
Packaging: Carton boxess, Cupboard , EPE, Blister Tray, About the package way, it is up to the size of products,
according to customer request and demand. Different countries have not same requirement..
Shipping: Express way as DHL,Fedex,EMS,UPS,air shipping,sea shipping,Any shipping method you prefer.
Payment Method:
Our Services:
1. Free repair within one year after the shipment of products from us.
2. Replacement within 30 days after the shipment of products from us due to products' problems.
3. We can print your logo and stick your model No.on the cameras.
4. We have long cooperation with many shipping companies and our export volume is large. The shipping companies
can offer us good discounts.
5. Professional technician supports. We have a good after-sales service team. They can solve your problems in time.
6.All goods will be inspected and tested by our engineers and QC/QA before packing and shipment.
7.Customers satisfactory is most important to us.If you have any problem or questions regarding our transaction.Please contact us by Email or online. It will be responded within 24 hours.
8.Products pictures only for your reference. please kindly refer to the specification. we can provide the products basic on the specification. or you can offer your own specification or drawing , we can customize all kinds of LCD displays for you. thanks for your kind support always.
Products Application field:
Audio product Medical Equipment
Industrial product(watermeter, electronicmeter,Equipment )
Automobiles Sports Equipment Watches
Household appliance(air condition/wash machine/electronic cooler/ refrigerator/disinfection cabinet/ wash bowl machine/ calculator /electronic scale etc.)
