Home /Products/7 Segment LCD Display/STN Negative 7 Segment LCD Display 3.3 V LCD Display With PIN Connector

STN Negative 7 Segment LCD Display 3.3 V LCD Display With PIN Connector

1000
MOQ
0.1-5USD
Price
STN Negative 7 Segment LCD Display 3.3 V LCD Display With PIN Connector
Features Gallery Product Description Request A Quote
Features
Specifications
Polarizer: Transmissive
View Angle Direction: 6 O'clock
Polarizer Type: Transmissive
Backlight Type: Green LEDs
Operating Temp: -40ºC+85ºC
Display Mode: Negative
Display Color: White
Bias: 1/4
Name: 7 Segment LCD Display
Highlight:

PIN Connector STN LCD Display

,

Negative 7 Segment LCD Display

,

3.3 V LCD Display 7 Segment
Basic Infomation
Place of Origin: China
Brand Name: BBI
Certification: ISO9001,RoHS,CE,REACH,SGS
Model Number: BBI-001
Payment & Shipping Terms
Packaging Details: CARTON
Delivery Time: 20-30DAYS
Payment Terms: T/T D/P Paypal
Supply Ability: 5000000/months
Product Description
STN Negative 7 Segment LCD Display 3.3 V LCD Display With PIN Connector

Advantages of STN Segment LCDs:


  • Better Contrast: Compared to regular TN displays, STN displays provide much higher contrast, making the text and numbers sharper and clearer.
  • Improved Viewing Angles: STN displays offer wider viewing angles, which is especially beneficial for applications where the display needs to be read from different angles.
  • Color Options: STN displays can be designed to support two colors (monochrome plus a secondary color) or even inverted colors, such as light characters on a dark background or dark characters on a light background.
  • Power Efficient: Like most LCDs, STN segment displays use very little power, making them ideal for portable or battery-powered devices.
  • Cost-Effective: STN technology is still less expensive than newer technologies like IPS and OLED while offering substantial improvements over TN in terms of visibility.



Detailed Parameters:


Model number GY88128-54 LCD type Segmented Display
Module Size 60(W)* 46(H)* 14.1(T) mm Display mode STN, Negative
LCD viewing area 50(W)* 31(H) mm Polarizer type Transmissive
Driver IC HT1621 LED backlight White
Drive method 1/4 Duty, 1/3 Bias Working voltage 3.3V
Viewing angle 12 O'clock Connection Way PIN, 24 numbers
Operate temperature 0℃~+50℃ Storage temperature -10~+60℃


Tag:

Seven Segment LCD Display

Segment LCD Module

TN LCD Display
