Name: 3.97 Inch TFT LCD Screen with 480x800 Dots Resolution and MIPI Interface
Brand: Dongguan Bibuke Electronic Technology Co., Ltd.
SKU: BBI-001
Price: 3.70 USD
Availability: InStock

Features Gallery Product Description Chat Now

Features

Specifications

Refresh Rate: 60 Hz

Backlight Type: LED

Interface: MIPI

Color Gamut: 72% NTSC

Luminance: 300 Cd/m2

Resolution: 480x800 Dots

Name: TFT LCD Display

Highlight:

IPS LCD TFT Screen

3.97 Inch LCD TFT Screen

IPS TFT Screen Display

Basic Infomation

Place of Origin: China

Brand Name: BBI

Certification: ISO9001 RoHS

Model Number: BBI-001

Document: Product Brochure PDF

Payment & Shipping Terms

Packaging Details: CARTON

Delivery Time: 3-4WEEKS

Payment Terms: T/T

Supply Ability: 100000/MONTH

Gallery

3.97 Inch TFT LCD Screen with 480x800 Dots Resolution and MIPI Interface

Product Description

3.97 Inch IPS LCD TFT Screen 480x800 Dots GC9503 24PIN FPC With MIPI Interface

Premium Display Solution

This 3.97-inch TFT LCD IPS screen features a 480×800 resolution with GC9503 driver IC and 24PIN FPC connector using MIPI interface technology.

Key Features

3.97-inch diagonal screen size for enhanced content display

480×800 WVGA resolution for sharp, clear visuals

16.7 million colors (24-bit color depth) for vibrant reproduction

LED backlighting for optimal brightness in various lighting conditions

Technical Specifications

Parameter	Specification
Product Name	3.97 Inch TFT LCD
LCD Type	Normally Black
Viewing Angle	Free
Resolution	480×800 dots
Operating Temperature	-20°C to +70°C
Storage Temperature	-30°C to +80°C
FPC Connector	24PIN, ZIF type
FPC Pitch	0.5 mm
Driver IC (COG)	GC9503
Interface	MIPI
Backlight Type	8-LED, White, 160mA
Luminance	300 cd/m²
Outline Dimension	57.14(H) × 96.85(V) × 2.20(D) mm
Active Area	51.84(H) × 86.35(V) mm

Advanced Display Technology

The screen utilizes a 3.97-inch IPS full-view panel with an active display area of 51.84×86.40mm. The compact module design measures approximately 57.14×96.85×2.20mm, featuring a slim profile ideal for space-constrained applications.

Equipped with GC9503 driver IC using COG (chip-on-glass) packaging, ensuring stable display signal output and smooth picture performance. The 24PIN ZIF type FPC combined with MIPI interface provides high transmission rates with low power consumption, compatible with mainstream embedded processors.

Operating temperature range: -20°C to +70°C | Storage temperature range: -30°C to +80°C

Certifications: ROHS compliant | Warranty: One year for non-artificial damage

Product Images
