7.6 Inch TFT LCD Display with 1000 Nits Brightness and 800x800 Pixels IPS Screen

1000
MOQ
0.7-7USD
Price
7.6 Inch TFT LCD Display with 1000 Nits Brightness and 800x800 Pixels IPS Screen
Features Gallery Product Description Chat Now
Features
Specifications
Backlight: White LED
Viewing Angle: IPS, All Viewing Angle (85/85/85/85)
Technology: LCD
Connection: ZIF FPC
Touch Screen: Yes
Display Technology: LCD
Brightness: 1000 Cd/m²
Lcd Type: TFT
Highlight:

7.6 Inch TFT LCD Display

,

1000 Nits IPS Screen

,

800x800 Pixels LCD Module
Basic Infomation
Place of Origin: China
Brand Name: BBI
Certification: ISO9001 RoHS
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: CARTON
Delivery Time: 3-4WEEKS
Payment Terms: T/T
Supply Ability: 100000/MONTH
Product Description
7.6 Inch TFT LCD Display 1000 Nits 800x800 Pixels Square Type IPS Screen
General Specifications
Product 7.6 Inch Square LCD Display
Resolution 800×800 Dots
Interface MIPI
Surface Luminance 1000 Cd/m² (nits)
Viewing Direction IPS, All Viewing Angle (85/85/85/85)
Touch Screen Customizable
LCD Controller ILI9881C
Cover Glass Dimension Customizable
Operating Temperature -20°C to +70°C
Storage Temperature -25°C to +75°C
Brightness 1000 Nits
Connection ZIF FPC
LED Lifetime 40,000 Hours
Compliance REACH & RoHS Compliant
Product Quick Review
  • Square LCD Display
  • Size: 7.6 inch
  • Resolution: 800×800 dots
  • View Direction: IPS
  • Interface: MIPI
  • Driver IC: ILI9881C
  • Control-Board: No
  • Brightness: 1000 cd/m²
  • Frame Through Hole: No
  • Touch Screen: Projected Capacitive Touch Panel (PCAP) optional
  • Detect Point: 5 Fingers
  • Operating Temperature: -20°C to +70°C (Wide Temperature)
Product Description
This TFT LCD module features a 7.6-inch square diagonal size with 800×800 pixel resolution. Equipped with an ILI9881C integrated circuit that combines controller and driver IC functions, it supports MIPI interface with a power supply voltage range of 2.5V to 3.6V (typical 3.3V). The IPS viewing technology provides full viewing angles (85/85/85/85 max).
With exceptional brightness of 1000 nits, this 7.6-inch IPS TFT LCD operates in temperatures from -20°C to +70°C and stores between -25°C to +75°C. Suitable for both indoor and outdoor applications, this high-performance display solution meets diverse requirements for industrial equipment, scanners, home automation, access control systems, monitoring equipment, analyzers, security systems, garden irrigation systems, and numerous other applications.
7.6 Inch TFT LCD Display with 1000 Nits Brightness and 800x800 Pixels IPS Screen 0 7.6 Inch TFT LCD Display with 1000 Nits Brightness and 800x800 Pixels IPS Screen 1 7.6 Inch TFT LCD Display with 1000 Nits Brightness and 800x800 Pixels IPS Screen 2
Frequently Asked Questions
I want the LCD display 8 digits and the outline size is 65x30x2.8mm?
No problem. Please send us your specifications or drawing. If you don't have specifications, you can provide samples; we will recommend suitable standard products or customize based on your requirements.
This LCD is just what we want, but it is big size, do you have any smaller size? And the display content need to be changed a little.
For segment type LCD modules requiring outline size or display content modifications, a new LCD glass module is needed, requiring new tooling.
This LCD display is HTN type, but I want STN type, can you make?
Yes, we can modify the display type according to your requirements.
I want to customize a new LCD module. Can you do?
Yes, we can. Please provide your drawing or specify the outline size, display information (glass thickness, polarizer, display type, connector mode, storage temperature, operating temperature, supply voltage, viewing direction, drive conditions).
What is leading time for tooling?
Typically 15 to 25 days after drawing confirmation and tooling charge payment. We will provide exact timing upon drawing confirmation.
Can you send us samples for checking?
Yes, sample orders are available.
What is the Leading Time?
For standard products in stock, lead time is one day after payment. For mass production of special orders, lead time is approximately 15-30 days. We will notify you in advance if we can complete earlier.
