6.5 Inch 800x480 Industrial RGB Interface 50 Pin With Touch TFT LCD Display
6.5 Inch 800x480 Industrial RGB Interface 50 Pin With Touch TFT LCD Display
Product Introduction
| Keywords: |
6.5 Inch TFT LCD Display |
| Resolution: |
800x480 |
| Interface: |
RGB |
| LED Lifetime: |
40,000 Hours |
| Viewing Direction: |
6 O'clock |
| Operating Temp.: |
-20℃ To +70℃ |
| Touch Screen: |
Resistive Touch Panel |
| Cover Glass Dimension: |
ODM |
| Surface Luminance: |
320 Cd/m2 |
| Pins: |
50 |
| Connection: |
ZIF / Plugging |
This is an industrial-grade TFT LCD display module with a 6.5-inch size and a resolution of 800×480 (WVGA). It adopts a 50-pin RGB parallel interface and integrates a capacitive touch screen. It is specially designed for high stability and high definition in embedded and industrial applications.
Display Characteristics
- Size: 6.5 inches, widescreen with a 17:9 aspect ratio
- Resolution: 800×480 (WVGA), with fine picture quality, capable of clearly displaying text, charts and images
- Brightness: Typical 400-450 cd/m², some customized versions can reach 700 cd/m², suitable for medium brightness environments indoors and outdoors
- Contrast: 500:1, with natural color reproduction and clear display layers
- Viewing Angle: Horizontal/vertical approximately 70°/50°, meeting the multi-angle viewing requirements of industrial scenarios
- Backlight: WLED, with a lifespan of approximately 50,000 hours, low power consumption and stability
Interfaces and Touch
- Interfaces: 50-pin 24-bit RGB parallel interface, high-speed transmission, good picture quality, high refresh rate, suitable for mainstream embedded controllers such as STM32, FPGA
- Touch: Integrated capacitive touch screen, supporting multi-touch, sensitive response, high precision, surface hardness up to 6H, scratch-resistant and wear-resistant
- Driver IC: Commonly used capacitive touch IC (such as GT911), plug-and-play
Structure and Environment
- Dimensions: Approximately 155.2×89.4×5.5 mm, display area 143.4×76.7 mm, compact and lightweight, suitable for embedded installation in devices
- Operating Temperature: -30°C to +85°C, industrial-grade wide temperature range, suitable for harsh working conditions
- Reliability: Anti-interference, shock resistance, dust-proof, meeting the requirements for long-term stable operation of industrial equipment
Main Applications
- Industrial Control HMI: PLC human-machine interface, production line operation panel, equipment control cabinet terminal, used for displaying parameters, status and interaction
- Medical Equipment: Portable monitor, health detector, small B-ultrasound, etc., displaying vital sign data and detection images, balancing portability and clarity
- Vehicle Electronics: Vehicle central control panel, navigator, rearview camera display, suitable for interior brightness and temperature environments, convenient touch operation
- Smart Home: Smart control panel, visible doorbell, home energy management terminal, providing intuitive interaction interface
- Embedded Development: STM32/FPGA development board, DIY project prototype, 50-pin RGB interface with strong universality, suitable for most controllers, convenient for development and debugging
- Security and IoT: Access terminal, monitoring display, IoT data collector, stable display of monitoring images and data information
Product Drawing
