Custom Zebra/Pin Interface LCD Display with Industrial-Grade Anti-Interference and Wide Temperature Range for Detection Instruments

1000
MOQ
0.7-7USD
Price
Custom Zebra/Pin Interface LCD Display with Industrial-Grade Anti-Interference and Wide Temperature Range for Detection Instruments
Features Gallery Product Description Chat Now
Features
Specifications
Display Technology: LCD
Connect: Pin
Outline Size: 50.80 X 30.48
Size: Customized
Backlight Technology: LED
Va Size: 45.80 X 17.86
Product Type: TN LCD Display
Digital Height (mm): 12.7
Highlight:

Custom Zebra/Pin Interface LCD Display

,

Industrial-Grade Anti-Interference LCD Display

,

Wide Temperature Range TN LCD Panel
Basic Infomation
Place of Origin: China
Brand Name: BBI
Certification: ISO9001 RoHS
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: CARTON
Delivery Time: 3-4WEEKS
Payment Terms: T/T
Supply Ability: 100000/MONTH
Product Description
Zebra / Pin Custom LCD Display TN STN Type
Small LCD display designed for detection instruments and industrial tools, offering TN and STN technology options with flexible interface customization.
Product Specifications
Type TN LCD Display
Storage Temperature -20°C to +70°C
Voltage 2.8 V
Connector Pin
Driving Method Static
Polarizer Type Reflective
Number of Digitals 3 1/2 (Lowbat and plus/minus)
LCD Mode TN Positive
Glass Size (W*H) 50.80 mm * 30.48 mm
View Area (W*H) 45.80 mm * 17.86 mm
Digital Height 12.7 mm
Operating Voltage 5.0 V
Custom Zebra/Pin Interface LCD Display with Industrial-Grade Anti-Interference and Wide Temperature Range for Detection Instruments 0 Custom Zebra/Pin Interface LCD Display with Industrial-Grade Anti-Interference and Wide Temperature Range for Detection Instruments 1
Key Features
Dual Technology Options
  • TN Type: Fast response speed (≤10ms) with ultra-low power consumption (μA level), ideal for portable tools and battery-powered devices with real-time display requirements
  • STN Type: High contrast (≥300:1) with wide viewing angles (≥120°), supports negative/positive display customization for multi-angle observation scenarios
Flexible Interface Customization
  • Zebra Strip Interface: Ultra-thin flexible connection for compact spaces, excellent shock resistance, prevents interface loosening in vibrating environments
  • Pin Interface: Multiple pin configurations (4-20Pin) with customizable spacing, compatible with PLC controllers and microcontrollers
Comprehensive Customization Capabilities
  • Display Parameters: Supports 1-8 bit code, dot matrix display, character height ≥3mm, custom unit symbols and alarm indicators
  • Size & Structure: Standard size range 15mm*25mm~50mm*80mm, thickness ≤2.8mm, waterproof, scratch-resistant, and oil-resistant surface treatments
  • Function Customization: Backlight options (red, green, yellow, blue), high/low temperature alarm display, status indicators, wide temperature operation (-20°C~70°C)
Industrial-Grade Reliability
  • Anti-Interference: EMC electromagnetic compatibility certified, resistant to industrial electromagnetic radiation and voltage fluctuations
  • Durability Testing: Extensive high/low temperature cycling, salt spray, vibration, and aging tests with MTBF ≥60,000 hours
  • Environmental Compliance: Mercury-free, low-power materials, RoHS and CE certified
Core Application Scenarios
Small Detection Instruments
Handheld pressure detectors, temperature inspection instruments, gas sensors, water quality analyzers. Low power consumption and compact design with clear data presentation for efficient detection operations.
Industrial Tools & Control Equipment
Electric wrenches, torque testers, welding parameter regulators, small PLC controllers. Industrial-grade anti-interference and shock resistance for precise parameter control.
Assembly Lines & Automation
Counters, speedometers, displacement sensors, control cabinet instruments. Wide viewing angles and stable connections for continuous 24/7 operation.
Outdoor & Extreme Environments
Outdoor environmental monitors, mine safety instruments, high-temperature workshop equipment. Wide temperature operation and clear display in harsh conditions.
Packaging & Shipping
Packaging: Carton boxes, cupboard, EPE, blister tray. Custom packaging solutions available based on product size and customer requirements.
Custom Zebra/Pin Interface LCD Display with Industrial-Grade Anti-Interference and Wide Temperature Range for Detection Instruments 2
Shipping: Express services including DHL, FedEx, EMS, UPS, air shipping, and sea shipping. Multiple shipping methods available to suit customer preferences.
Custom Zebra/Pin Interface LCD Display with Industrial-Grade Anti-Interference and Wide Temperature Range for Detection Instruments 3
Payment Methods
Custom Zebra/Pin Interface LCD Display with Industrial-Grade Anti-Interference and Wide Temperature Range for Detection Instruments 4

Custom Zebra/Pin Interface LCD Display with Industrial-Grade Anti-Interference and Wide Temperature Range for Detection Instruments 5
