Name: 3.3V 1.54 Inch OLED Screen 128x64 White Blue Yellow With SPD0301 Driver IC
Brand: Dongguan Bibuke Electronic Technology Co., Ltd.
SKU: BBI-001
Availability: InStock

3.3V 1.54 Inch OLED Screen 128x64 White Blue Yellow With SPD0301 Driver IC

1000

MOQ

DISCUSSABLE

Price

Features Gallery Product Description Chat Now

Features

Specifications

Driver Ic: SPD0301

Sizes Range: 1.54 Inch

Display Color: Blue Or White Or Yellow

Aspect Ratio: 16:9

Backlight: 4 Chip White LED, 4PVF =3.2+1.0V;IF=80mA

Operating Temperature: -40~+70℃

Name: OLED Display

Highlight:

3.3V OLED Screen

1.54 Inch OLED Screen

OLED Screen 128x64

Basic Infomation

Place of Origin: China

Brand Name: BBI

Certification: ISO9001 RoHS

Model Number: BBI-001

Payment & Shipping Terms

Packaging Details: CARTON

Delivery Time: 3-4WEEKS

Payment Terms: T/T

Supply Ability: 100000/MONTH

Gallery

3.3V 1.54 Inch OLED Screen 128x64 White Blue Yellow With SPD0301 Driver IC

Product Description

3.3V 1.54 Inch OLED Display 128x64 White Blue Yellow With SPD0301 Driver IC

Product Description

Key Features:

Display Resolution: Depending on the module, typically 128x64 pixels or 128x128 pixels.
Interface: Common interfaces include I2C or SPI, making them easy to connect with microcontrollers like Arduino, Raspberry Pi, or ESP32.
Power Consumption: OLEDs are known for low power consumption, especially when displaying darker content since they don't require a backlight.
Color Display: Many 1.54-inch OLED modules offer monochrome versions (e.g., white, blue, or yellow) are available.
Shape: The display can be square or rectangular, which depends on your designs.

Detailed Parameters:

1	Brand Name	Bibuke
2	Model Description	1.54 Inch OLED Display
3	Display Mode	OLED(Organic Light Emitting Diode)
4	Display Color	Blue or White or Yellow
5	Panel Size	1.54 Inch
6	Dot Matrix	128*64 Pixels
7	Module Size	42.04(W) x 37.0(H) mm
8	View Area	37.06(W) x19.52(H) mm
9	Active Area	35.06(W) x17.52(H) mm
10	Drive IC	SPD0301
11	Interface	4-wire SPI
12	Operating Temperature	-40~+70℃
13	Voltage	3.3V
14	PIN Pitch	2.54 mm

3.3V 1.54 Inch OLED Screen 128x64 White Blue Yellow With SPD0301 Driver IC 0

3.3V 1.54 Inch OLED Screen 128x64 White Blue Yellow With SPD0301 Driver IC 1

3.3V 1.54 Inch OLED Screen 128x64 White Blue Yellow With SPD0301 Driver IC 2

Products Application field:

Audio product Medical Equipment

Industrial product(watermeter, electronicmeter,Equipment )

Automobiles Sports Equipment Watches

Household appliance(air condition/wash machine/electronic cooler/ refrigerator/disinfection cabinet/ wash bowl machine/ calculator /electronic scale etc.)
