Name: 1.54 Inch Monochrome OLED Display Module 128x64 Dots CH1116 IIC Interface
Brand: Dongguan Bibuke Electronic Technology Co., Ltd.
SKU: BBI-001
Price: 2.10 USD
Availability: InStock

1.54 Inch Monochrome OLED Display Module 128x64 Dots CH1116 IIC Interface

1000

MOQ

0.1-5USD

Price

Features Gallery Product Description Request A Quote

Features

Specifications

Durability: Varies, Typically Between 20,000-100,000 Hours

Operating Temp: -20°C ~ +70°C

Panel Size: 3.12 Inch (diagonal)

Lcm Interface: 6800,8080,SPI,I2C

Type: OLED

Response Time: Varies, Typically Between 0.01-0.1 Ms

Viewing Angle: Varies, Typically Between 160-178 Degrees

Weight: Varies, Typically Between 10-100 Grams

Name: OLED Display

Highlight:

Monochrome OLED Display 1.54 Inch

Monochrome OLED Display Module

Monochrome OLED Module 128x64

Basic Infomation

Place of Origin: China

Brand Name: BBI

Certification: ISO9001,RoHS,CE,REACH,SGS

Model Number: BBI-001

Payment & Shipping Terms

Packaging Details: CARTON

Delivery Time: 20-30DAYS

Payment Terms: T/T D/P Paypal

Supply Ability: 5000000/months

Gallery

1.54 Inch Monochrome OLED Display Module 128x64 Dots CH1116 IIC Interface

Product Description

Product Description

1.54 Inch Monochrome OLED Display Module 128x64 Dots CH1116 IIC Interface

Types of 1.54-inch OLED Modules:

Monochrome OLED (Black/White):
- Resolution: 128x64 pixels (common).
- Controller: Typically SSD1309, CH1116, or SPD0301.
- Interface: SPI or I2C.
- Color: Black and white (monochrome).

For an I2C interface, the pinout would typically include:

VCC: Power supply (3.3V or 5V).
GND: Ground.
SDA: Serial Data Line (I2C).
SCL: Serial Clock Line (I2C).
RESET: Reset pin (sometimes optional for I2C).

Detailed Parameters:

1	Brand Name	Bibuke
2	Model Description	1.54 Inch Monochrome OLED Display
3	Display Mode	OLED(Organic Light Emitting Diode)
4	Display Color	Blue or White
5	Panel Size	1.54 Inch
6	Dot Matrix	128*64 Pixels
7	Module Size	42.4(W) x 38.0(H) x 3.9(D) mm
8	Active Area	35.06(W) x17.52(H) mm
9	Dot Size	0.254(W)*0.254(H) mm
10	Dot Pitch	0.274(W)*0.274(H) mm
11	Drive IC	CH1116
12	Interface	I2C
13	Operating Temperature	-40~+70℃
14	Drive Method	3~5V
15	PIN Header	Optional
