Name: Serial Interface 1.54 Inch OLED Display Panel Blue Color 128x64 Dots 24PIN
Brand: Dongguan Bibuke Electronic Technology Co., Ltd.
SKU: BBI-001
Price: 2.10 USD
Availability: InStock

Serial Interface 1.54 Inch OLED Display Panel Blue Color 128x64 Dots 24PIN

1000

MOQ

0.1-5USD

Price

Features Gallery Product Description Request A Quote

Features

Specifications

Backlight: 4 Chip White LED, 4PVF =3.2+1.0V;IF=80mA

Resolution: Varies By Model

Pins: 14P

Display: Oled

Contrast Ratio: Varies By Model

Type: PMOLED

Outline Screen Size: 42.04 *27.22 *1.45 Mm

Color Depth: 16.7 Million Colors

Name: OLED Display

Highlight:

Serial Interface OLED Display

1.54 Inch OLED Display Panel

OLED Panel Display 128x64

Basic Infomation

Place of Origin: China

Brand Name: BBI

Certification: ISO9001,RoHS,CE,REACH,SGS

Model Number: BBI-001

Payment & Shipping Terms

Packaging Details: CARTON

Delivery Time: 20-30DAYS

Payment Terms: T/T D/P Paypal

Supply Ability: 5000000/months

Gallery

Serial Interface 1.54 Inch OLED Display Panel Blue Color 128x64 Dots 24PIN

Product Description

Product Description

Serial Interface 1.54 Inch OLED Display Panel Blue Color 128x64 Dots 24PIN

The 1.54-inch OLED SPD0301 display is a small, monochrome or color OLED display that uses the SPD0301 controller. It's commonly used in embedded systems, smartwatches, fitness trackers, and other portable devices that need a compact, low-power display.

SPD0301 Controller Overview:

The SPD0301 is an OLED driver/controller that supports both monochrome and color OLED displays. It is typically used in small, low-power applications. It supports SPI (and potentially I2C) interfaces for communication with a microcontroller.

While the SPD0301 controller is not as common as other OLED controllers like the SSD1306, it is still widely supported in some libraries for use with Arduino and other microcontrollers.

Detailed Parameters:

1	Brand Name	Bibuke
2	Model Description	Serial Interface 1.54 Inch OLED Display
3	Display Mode	OLED(Organic Light Emitting Diode)
4	Color	Blue
5	Size	1.54 Inch
6	Dot Matrix	128*64 Pixels
7	Module Size	42.04(W)x27.22(H)x1.41(D) mm
8	View Area	37.052 (W) x 19.516(H) mm
9	Active Area	35.052(W) x17.516(H) mm
10	Dot Size	0.254(W)*0.254(H) mm
11	Dot Pitch	0.274(W)*0.274(H) mm
12	Drive IC	SPD0301ZD
13	Interface	6800/8080 interface, 4 wire serial interface, I2C
14	FPC Connector	24PIN, socket type
15	FPC Pitch	0.5 mm
16	Drive Method	VDD=1.65V~3.3V, Vin=11.5~12.5V
17	Viewing Angle	160°
