Name: High Contrast 1.54'' OLED Display White Color 128x64 Resolution SPD0301 24pin FPC
Brand: Dongguan Bibuke Electronic Technology Co., Ltd.
SKU: BBI-001
Price: 2.10 USD
Availability: InStock

High Contrast 1.54'' OLED Display White Color 128x64 Resolution SPD0301 24pin FPC

1000

MOQ

0.1-5USD

Price

Features Gallery Product Description Request A Quote

Features

Specifications

Response Time: Less Than 0.01 Milliseconds

Touch Panel: Oncell Touch

Luminance: 350nits

Outline Dimension: 81.00*138.20(mm)

Active Area: 68.26*121.34(mm)

Size: 5.5 Inch

Lcd Driver Ic: SSD1327ZB

Contrast Ratio: Varies, Typically Between 100,000:1 To 1,000,000:1

Name: OLED Display

Highlight:

High Contrast OLED Display

1.54" OLED Display 24pin

1.54 OLED Display SPD0301

Basic Infomation

Place of Origin: China

Brand Name: BBI

Certification: ISO9001,RoHS,CE,REACH,SGS

Model Number: BBI-001

Payment & Shipping Terms

Packaging Details: CARTON

Delivery Time: 20-30DAYS

Payment Terms: T/T D/P Paypal

Supply Ability: 5000000/months

Gallery

High Contrast 1.54'' OLED Display White Color 128x64 Resolution SPD0301 24pin FPC

Product Description

Product Description

High Contrast 1.54'' OLED Display White Color 128x64 Resolution SPD0301 24pin FPC

Key Features of the 1.54-inch PMOLED 128x64 Display:

Display Size: 1.54 inches (diagonal).
Resolution: 128x64 pixels (monochrome).
Technology: PMOLED (Passive Matrix OLED), typically black-and-white.
Controller IC: Common controllers for such displays include SSD1309 or other similar drivers.
Interface: Most commonly I2C or SPI.
Low Power Consumption: OLED technology is energy-efficient, especially when displaying dark content.
High Contrast: OLED displays provide true blacks and high contrast, which results in clear visibility.

Detailed Parameters:

1	Brand Name	Bibuke
2	Model Description	High Contrast 1.54'' OLED Display
3	Display Mode	OLED(Organic Light Emitting Diode)
4	Color	White
5	Size	1.54 Inch
6	Dot Matrix	128*64 Pixels
7	Module Size	42.04(W)x27.22(H)x1.41(D) mm
8	View Area	37.052 (W) x 19.516(H) mm
9	Active Area	35.052(W) x17.516(H) mm
10	Dot Size	0.254(W)*0.254(H) mm
11	Dot Pitch	0.274(W)*0.274(H) mm
12	Drive IC	SPD0301ZD
13	Interface	6800/8080 interface, 4 wire serial interface, I2C
14	FPC Connector	24PIN, socket type
15	FPC Pitch	0.5 mm
16	Drive Method	VDD=1.65V~3.3V, Vin=11.5~12.5V
17	Viewing Angle	160°
