15.6 Inches Mono LCD Display 240x128 Dot Matrix 1/ 128 Duty 5V DC/DC

1000

MOQ

0.1-5USD

Price

Features Gallery Product Description Request A Quote

Features

Specifications

Brightness: 250 Cd/m2

Contrast Ratio: 1000:1

Weight: 2.4 Pounds

Dimensions: 14.8 X 9.3 X 1.7 Inches

Backlight Technology: LED

Screen Size: 15.6 Inches

Interface Type: HDMI, VGA

Aspect Ratio: 16:9

Name: Monochrome LCD Display

Highlight:

Mono LCD Display Dot Matrix

Mono LCD Display 240x128

15.6 inches Monochrome LCD Panel

Basic Infomation

Place of Origin: China

Brand Name: BBI

Certification: ISO9001,RoHS,CE,REACH,SGS

Document: BBI-F-BM-240128_spec.pdf

Payment & Shipping Terms

Packaging Details: CARTON

Delivery Time: 20-30DAYS

Payment Terms: T/T D/P Paypal

Supply Ability: 5000000/months

Gallery

15.6 Inches Mono LCD Display 240x128 Dot Matrix 1/ 128 Duty 5V DC/DC

Product Description

Monochrome LCD Display 240 ´ 128 Dot-Matrix ; 1/ 128 Duty 5V DC/DC

General Specification:

1 FEATURES

(1) Display format : 240 ´ 128 dot-matrix ; 1/ 128 duty.

(2) Construction : STN/FSTN LCD, Bezel, Zebra ,PCB.

(3) Optional LED / EL / CCFL back-light.

(4) Built in controller T6963C or EQU.

(5) 5V single power input. Built-in DC/DC converter for LCD driving.

(6) Normal / Extended temperature type.

2 MECHANICAL DATA

Parameter	Standard Value	Unit
Dot size	0.40 (W) ´ 0.40(H)	mm
Dot pitch	0.45(W) ´ 0.45(H)	mm
Viewing area	114.0(W) ´ 64.0(H)	mm

Module size (LED/CCFL back-light)	144.0(W) ´ 104.0(H) ´ 13.7 max (T)	mm

3 ABSOLUTE MAXIMUM RATINGS

Parameter		Symbol	Min	Max	Unit
Logic Circuit Supply Voltage		VDD-VSS	0	7.0	V
LCD Driving Voltage		VDD-VO	0	26	V
Input Voltage		VI	VSS	VDD	V
Normal temp. type	Operating Temp.	TOP	0	50	°C
Normal temp. type	Storage Temp.	TSTG	-20	70	°C
Extended temp. type	Operating Temp.	TOP	-20	70	°C
Extended temp. type	Storage Temp.	TSTG	-30	80	°C
