TN Tranflective Custom Small LCD Positive Display Module

Model

Content
CharsXLines

Module size
W x H(mm)

View area
W x H(mm)

Dot size
W x H(mm)

Character size W x H(mm)

Driving Method

Controller LSI or Equiv

IC
Package

STN-TYPE

FSTN-TYPE

8D-C0802A

8X2

84.0X44.0

63.0X25.0

1.15X1.36

6.07X11.56

1/16

S6A0069

COB

Y

Y

8D-C0802B

8X2

58.0X32.0

38.0X16.0

0.56X0.66

2.95X5.56

1/16

S6A0069

COB

Y

Y

8D-C1202A

12X2

55.7X32.0

46.7X17.5

0.45X0.6

2.65X5.5

1/16

S6A0069

COB

Y

Y

8D-C1601A

16X1

80.0X36.0

64.5X13.8

0.55X0.65

3.2X5.95

1/16

S6A0069

COB

Y

Y

8D-C1601B

16X1

122.0X33.0

99.0X13.0

0.92X1.1

4.84X8.06

1/16

S6A0069

COB

Y

Y

8D -C1601C

16X1

80.0X36.0

64.5X13.8

0.6X0.7

3.2X8.2

1/11

S6A0069

COB

Y

Y

8D -C1601D

16X1

85.0X28.0

65.0X16.0

0.55X0.75

3.07X6.56

1/16

S6A0069

COB

Y

Y

8D -C1601E

16X1

80.0X36.0

64.5X13.8

0.55X0.75

3.07X6.56

1/16

S6A0069

COB

Y

Y

8D -C1602A

16X2

80.0X36.0

64.5X13.8

0.55X0.5

2.95X4.35

1/16

S6A0069

COB

Y

Y

8D -C1602B

16X2

122.0X44.0

99.0X24.0

0.92X1.1

4.84X9.66

1/16

S6A0069

COB

Y

Y

8D -C1602C

16X2

80.0X36.0

64.5X15.5

0.55X0.66

2.96X5.56

1/16

S6A0069

COB

Y

Y

8D -C1602D

16X2

84.0X44.0

64.5X15.5

0.55X0.66

2.96X5.56

1/16

S6A0069

COB

Y

Y

8D -C1602E

16X2

85.0X36.0

64.5X15.5

0.56X0.66

2.96X5.56

1/16

S6A0069

COB

Y

Y

8D -C1602F

16X2

72.0X36.0

64.5X15.5

0.56X0.66

2.96X5.56

1/16

S6A0069

COB

Y

Y

8D -C1604A

16X4

87.0X60.0

62.0X25.6

0.55X0.55

2.95X4.75

1/16

S6A0069

COB

Y

Y

8D -C2001A

20X1

116.0X37.0

83.0X18.6

0.6X0.65

3.2X5.55

1/16

S6A0069

COB

Y

Y

8D -C2002A

20X2

98.0X60.0

83.0X18.6

0.6X0.65

3.2X5.55

1/16

S6A0069

COB

Y

Y

8D -C2002B

20X2

116.0X37.0

83.0X18.6

0.6X0.65

3.2X5.55

1/16

S6A0069

COB

Y

Y

8D -C200C

20X2

146.0X43.0

123.0X23.0

0.92X1.1

0.98X1.17

1/16

S6A0069

COB

Y

Y

Model

Content
 (W X H)

Module size
W x H(mm)

View area
W x H(mm)

Dot size
W x H(mm)

Dot pitch
W x H(mm)

Driving Method

Controller LSI or Equiv

IC
Package

STN-TYPE

FSTN-TYPE

8D -C2004A

20X4

98.0X60.0

76.0X25.2

0.55X0.55

2.95X4.75

1/16

S6A0069

COB

Y

Y

8D -C2004B

20X4

77.0X47.0

60.0X22.0

0.42X0.46

2.3X4.03

1/16

S6A0070

COB

Y

Y

8D -C2004C

20X4

146.0X62.5

123.5X43.0

0.92X1.1

4.84X9.22

1/16

S6A0069

COB

Y

Y

8D -C2402A

24X2

118.0X36.0

93.5X16.0

0.6X0.65

3.2X5.55

1/16

S6A0069

COB

Y

Y

8D -C2402B

24X2

208.0X40.0

178.0X23.0

1.16X1.16

6.0X9.63

1/16

S6A0069

COB

Y

Y

8D -C4001A

40X1

182.0X33.5

154.4X16.5

0.6X0.75

3.2X6.35

1/16

S6A0069

COB

Y

Y

8D -C4002B

40X2

182.0X33.5

154.4X16.5

0.6X0.65

3.2X5.55

1/16

S6A0069

COB

Y

Y

8D C4004A

40X4

190.0X54.0

147.0X29.5

0.5X0.55

2.78X4.89

1/16

S6A0069

COB

Y

Y

8D -G12232A

122X32

84.0X44.0

60.0X18.5

0.4X0.4

0.44X0.44

1/32

SED1520

COB

Y

Y

8D -G12232B

122X32

80.0X36.0

55.0X18.5

0.36X0.41

0.4X0.45

1/32

SED1520

COB

Y

Y

8D -G12232C

122X32

98.0X60.0

76.0X25.2

0.53X0.61

0.57X0.65

1/32

SED1520

COB

Y

Y

8D -G12232D

122X32

80.2X47.4

76.0X25.2

0.53X0.61

0.57X0.65

1/32

SED1520

COB

Y

Y

8D -G12864A

128X64

78.0X70.0

62.0X44.0

0.39X0.55

0.44X0.6

1/64

S6B0108A

COB

Y

Y

8D -G12864B

128X64

105.0X60.5

72.0X40.0

0.48X0.48

0.52X0.52

1/64

S6B0108A

COB

Y

Y

8D -G12864C

128X64

93.0X70.0

72.0X40.0

0.48X0.48

0.52X0.52

1/64

S6B0108A

COB

Y

Y

8D -G12864D

128X64

113.0X65.0

72.0X40.0

0.48X0.48

0.52X0.52

1/64

S6B0108A

COB

Y

Y

8D -G12864E

128X64

93.0X70.0

72.0X40.0

0.48X0.48

0.52X0.52

1/64

ST7920

COB

Y

Y

8D -G19264A

192X64

130X65.0

104.0X39.0

0.46X0.46

0.51X0.51

1/64

S6B0108A

COB

Y

Y

8D -G19264B

192X64

120X62.0

104.0X39.0

0.46X0.46

0.51X0.51

1/64

S6B0108A

COB

Y

Y

8D -G24064B

240X64

180.0X65.0

132.0X39.0

0.53X0.53

0.49X0.49

1/64

T6963C

QFP/COB

Y

Y

8D -G240128A

240X128

144X104

114X64

0.4X0.4

0.45X045

1/128

T6963C

QFP/COB

Y

Y
