Home /Products/Small LCD Display/Polcd 1.33 Inch Small LCD Display 4 Wire IPS 240x240 ST7789V RGB Vertical LCD Display

Polcd 1.33 Inch Small LCD Display 4 Wire IPS 240x240 ST7789V RGB Vertical LCD Display

1000
MOQ
0.1-5USD
Price
Polcd 1.33 Inch Small LCD Display 4 Wire IPS 240x240 ST7789V RGB Vertical LCD Display
Features Gallery Product Description Request A Quote
Features
Specifications
Viewing Angle: 160 Degrees
Operating Temperature: -20°C To 70°C
Cell Gap: 3.85+-0.3
Pixel Driving Element: A-Si TFT
Keywords: 2.4 Inch Lcd Display
Color Configuration: R.G.B. Vertical Stripe
Lcd Type: 12H
Input Data: 8bits /16bits Parallel Interface
Name: Small LCD Display
Highlight:

1.33 Inch Small LCD Display

,

Small LCD Display 4 Wire

,

RGB Vertical LCD Display
Basic Infomation
Place of Origin: China
Brand Name: BBI
Certification: ISO9001,RoHS,CE,REACH,SGS
Payment & Shipping Terms
Packaging Details: CARTON
Delivery Time: 20-30DAYS
Payment Terms: T/T D/P Paypal
Supply Ability: 5000000/months
Product Description

Polcd 1.33 Inch Small LCD Display 4 Wire Ips 240x240 ST7789V RGB Vertical Stripe

Product Description


P/N N133-2424TCBIG01-H12
Size(inch) 1.33
Resolution 240*240
Active Area(mm) 23.40*23.40
Pixel pitch(um) 97.5*97.5
Outline Dimension(mm) 26.16*29.22*1.5
Pixel arrangement RGB Vertical Stripe
Display Mode Normally Black
Viewing Angle ALL
Display colors 262K
Brightness
(cd/m²)		 350
Contrast Ratio 600:1
Interface 4 Wire SPI
Back-light LED Side-light type
Driver Ic ST7789V
Operation Temperature(°C) -20~70
Storage Temperature(°C) -30~80
Response time(ms) 35
Pin Number 12
Polcd 1.33 Inch Small LCD Display 4 Wire IPS 240x240 ST7789V RGB Vertical LCD Display 0 Polcd 1.33 Inch Small LCD Display 4 Wire IPS 240x240 ST7789V RGB Vertical LCD Display 1
Product Details
P/N:
N133-2424TCBIG01-H12
Size (inch):
1.33
Resolution:
240*240
Brightness (cd/m²):
350
Interface:
4 Wire SPI
Driver Ic:
ST7789V
Tag:

Small LCD Screen

Compact LCD Display

Vertical LCD Display
