1.9 Inch STN Blue LCD Display128x64 30PIN FPC 8 Bit Parallel LCD Display

1.9 Inch STN Blue LCD Display128x64 30PIN FPC 8 Bit Parallel LCD Display

Product Description

Advantages of STN Graphic LCD:

1. Low Power Consumption: Ideal for battery-powered devices, especially in reflective mode where no backlight is required.

2. Compact Size: The 128x64 resolution allows for a compact form factor while still being large enough for basic graphics and text.

3. Cost-Effective: These displays are often inexpensive compared to other graphical displays like TFT or OLED, making them a popular choice for budget-conscious designs.

4. Easy Integration: Many of these displays can be interfaced easily with microcontrollers and come with well-supported libraries for quick implementation.

5. Improved Visibility: Compared to TN displays, STN offers better contrast and wider viewing angles, which is beneficial for user interfaces that need to be viewed from different angles.

Detailed Parameters:

1	Product Description	Monochrome COG Graphic LCD Display
2	Model Brand	Bibuke
3	LCD Type	STN(Blue), Negative
4	Polarizer Type	Transmissive
5	Viewing Angle	6 O'clock
6	Resolution	128x64 dots
7	Drive Method	1/65 Duty, 1/9 Bias
8	Working Voltage	3.0V
9	Operating Temperature	-20~+70℃
10	Storage Temperature	-30~+80℃
11	FPC Connector	34PIN, soldering type
12	FPC Pitch	0.8mm
13	Driver IC	ST7565R
14	Interface	8-bit Parallel/ MCU
15	Backlight Type	2-LEDs, White, 30mA
16	Outline Dimension	47.6(W)* 38.0(H)* 5.2(T) mm
17	View Area	44(W)* 29(H) mm
18	Active Area	40.93(W)* 24.93(H) mm
19	Dot Size	0.29(W)* 0.36(H) mm
20	Dot Pitch	0.32(W)* 0.39(H) mm

---

Packaging & Shipping:

Packaging: Carton boxess, Cupboard , EPE, Blister Tray, About the package way, it is up to the size of products,

according to customer request and demand. Different countries have not same requirement..

Shipping: Express way as DHL,Fedex,EMS,UPS,air shipping,sea shipping,Any shipping method you prefer.

Payment Method:

FAQ:

1. I want the LCD display 8 digits and the outline size is 65x30x2.8mm………?

Answer: No problem. Firstly, please kindly send us your specification/ drawing paper

If you have not the specification, you can also provide your samples; we will recommend the suitable one

 if it is standard products. Or we can customize for you based on your own requirement.

2.This LCD  is just what we want, but it is big size, do you have any smaller size? And the display content need to be changed a little.
      Answer: For the segment type LCD module, if you need modify the outline size or display content,

a new LCD glass module is need. We have to open new tooling for you.

3. This LCD display is HTN type, but I want STN type,can you make?
      Answer: That’s all right .  we can change for you as per you request.

4. I want customize a new LCD module. Can you do?
      Answer: Yes, we can. Please send your drawing paper. If you have not, please advise me the outline size

of the LCD display, display information( Glass thickness, Polarizer, Display Type, Connector mode,
Storage Temp. Operating Temp.  Supply Voltage, Viewing direction, drive condition), we can customize for you.

5. What is leading time for tooling?
      Answer: General speaking, it will cost 15 to 25 days  after drawing paper confirmation and tooling charge payment,

we can report you the exact time when you confirm the drawing paper.

6. Can you send us samples for checking?
     Answer: Yes,. Samples order is available.

7. What is the Leading Time?
    Answer: If we have stock for the standard ones, the leading time is one day after payment. If it is the mass production for

special ones, the leading time is about 15-30 days. suppose we can finish earlier,  we will report the information in advanced.

Our Services:

1. Free repair within one year after the shipment of products from us.

2. Replacement within 30 days after the shipment of products from us due to products' problems.
3. We can print your logo and stick your model No.on the cameras.
4. We have long cooperation with many shipping companies and our export volume is large. The shipping companies

can offer us good discounts.
5. Professional technician supports. We have a good after-sales service team. They can solve your problems in time.
6.All goods will be inspected and tested by our engineers and QC/QA before packing and shipment.
7.Customers satisfactory is most important to us.If you have any problem or questions regarding our transaction.Please contact us by Email or online. It will be responded within 24 hours.

8.Products pictures only for your reference. please kindly refer to the specification. we can provide the products basic on the specification. or you can offer your own specification or drawing , we can customize all kinds of LCD displays for you. thanks for your kind support always.

Product application

Household appliances-refrigerators: air conditioners, fans, hot and cold air heaters, water heaters, electric blankets, heaters, air purifiers, washing machines, clothes dryers, vacuum cleaners, lampblack cleaners, microwave ovens, cookers, electric ovens, rice cookers, water drinkers, tea sets, etc.;

Communication :equipment-telephone, interphone, fax machine, wireless wifi, etc.

Automotive: electronics-on-board entertainment system, automobile fault detector, CarLog, vehicle navigator, car audio, reverse radar, reverse mirror, camera, anti-theft device, etc.

Instruments :water meters, electric meters, multimeter, electronic scales, pressure meters, temperature meters, flow meters, display instruments, electrical instruments, space instruments, measuring instruments, analytical instruments, electrochemical instruments, optical instruments, etc.;

Fitness: equipment-treadmill, waist machine, fitness bike, training device, pedometer, code table, beauty instrument, fat square measuring instrument, fitness instrument, electronic sphygmomanometer, weighing scale, etc.

 Financial :tax control-tax control cash machine, poss machine, usb-key cheque printer, banknote counting machine, tax control invoice machine, etc.

Consumer electronics:mp3,mp4,dvd, electronic dictionary, click reader, early teaching machine, learning machine, electronic organ, electronic clock, chronograph, calculator, etc.

high resolution, high definition, high brightness, cost-effective, energy conservation, high temperature, low temperature, Wide Temperature Range, Positive, Negative
